Professional Quality HSS Co Drill Left Hand HSS Twist Drills HSS Jobber Drill Bit (SED-HTL)

Quantity:
Inquire Add to Basket

  • Customized

  • DIN

  • Jobber-length

  • Twist Drill Bit

  • High Speed Steel

  • Metal Drilling

  • SED-HTL

  • 1.0mm-20mm

  • Left Hand

  • 135 Split Point, or 118

  • 2000PCS/Size

  • White,Black,Gold,Amber etc

  • PVC,Box,Set Case,Tube

  • PVC Bag, Blister Card, Plastic Box

  • left hand

  • EASYDRILL

  • China

  • 820750900

  • 200, 000PCS/Month

  • Available | Customized Request

Product Description

Professional quality HSS Co drill Left Hand HSS twist drills HSS Jobber Drill Bit

1. Material: 4241, 4341, 9341, 6542, M2, M35, and M42 +Co 5% etc. (pic:M2)
2. Manufacturing Art: Fully ground, roll forged and edge forged twist drill
3. Application: For drilling in steel, cast steel, malleable iron, sintered metal, non-ferrous metal and plastic,or wood.
4. Packing: Paper box, or Plastic box,punch bag,set case etc
5. Dia Size: 0.2mm-21mm
6.Surface finish:bright white,black,tin-coated, black&yellow,bronze coated etc
7.Standard: DIN338,DIN345,DIN340,DIN1897 etc
Professional Quality HSS Co Drill Left Hand HSS Twist Drills HSS Jobber Drill Bit (SED-HTL)
Diameter (mm) Flute Length(mm) Overall Length (mm) Diameter (mm) Flute Length(mm) Overall Length(mm) Diameter (mm) Flute Length(mm) Overall Length(mm)
0.2 2.5 19.0 5.6 57.0 93.0 11.0 94.0 142.0
0.3 3.0 19.0 5.7 57.0 93.0 11.1 94.0 142.0
0.4 5.0 20.0 5.8 57.0 93.0 11.2 94.0 142.0
0.5 6.0 22.0 5.9 57.0 93.0 11.3 94.0 142.0
0.6 7.0 24.0 6.0 57.0 93.0 11.4 94.0 142.0
0.7 9.0 28.0 6.1 63.0 101.0 11.5 94.0 142.0
0.8 10.0 30.0 6.2 63.0 101.0 11.6 94.0 142.0
0.9 11.0 32.0 6.3 63.0 101.0 11.7 94.0 142.0
1.0 12.0 34.0 6.4 63.0 101.0 11.8 94.0 142.0
1.1 14.0 36.0 6.5 63.0 101.0 11.9 101.0 151.0
1.2 16.0 38.0 6.6 63.0 101.0 12.0 101.0 151.0
1.3 16.0 38.0 6.7 63.0 101.0 12.1 101.0 151.0
1.4 18.0 40.0 6.8 69.0 109.0 12.2 101.0 151.0
1.5 18.0 40.0 6.9 69.0 109.0 12.3 101.0 151.0
1.6 20.0 43.0 7.0 69.0 109.0 12.4 101.0 151.0
1.7 20.0 43.0 7.1 69.0 109.0 12.5 101.0 151.0
1.8 22.0 46.0 7.2 69.0 109.0 12.6 101.0 151.0
1.9 22.0 46.0 7.3 69.0 109.0 12.7 101.0 151.0
2.0 24.0 49.0 7.4 69.0 109.0 12.8 101.0 151.0
2.1 24.0 49.0 7.5 69.0 109.0 12.9 101.0 151.0
2.2 27.0 53.0 7.6 75.0 117.0 13.0 101.0 151.0
2.3 27.0 53.0 7.7 75.0 117.0 13.1 101.0 151.0
2.4 30.0 57.0 7.8 75.0 117.0 13.2 101.0 151.0
2.5 30.0 57.0 7.9 75.0 117.0 13.3 108.0 160.0
2.6 30.0 57.0 8.0 75.0 117.0 13.4 108.0 160.0
2.7 33.0 61.0 8.1 75.0 117.0 13.5 108.0 160.0
2.8 33.0 61.0 8.2 75.0 117.0 13.6 108.0 160.0
2.9 33.0 61.0 8.3 75.0 117.0 13.7 108.0 160.0
3.0 33.0 61.0 8.4 75.0 117.0 13.8 108.0 160.0
3.1 36.0 65.0 8.5 75.0 117.0 13.9 108.0 160.0
3.2 36.0 65.0 8.6 81.0 125.0 14.0 108.0 160.0
3.3 36.0 65.0 8.7 81.0 125.0 14.3 114.0 169.0
3.4 39.0 70.0 8.8 81.0 125.0 14.5 114.0 169.0
3.5 39.0 70.0 8.9 81.0 125.0 14.8 114.0 169.0
3.6 39.0 70.0 9.0 81.0 125.0 15.0 114.0 169.0
3.7 39.0 70.0 9.1 81.0 125.0 15.3 120.0 178.0
3.8 43.0 75.0 9.2 81.0 125.0 15.5 120.0 178.0
3.9 43.0 75.0 9.3 81.0 125.0 15.8 120.0 178.0
4.0 43.0 75.0 9.4 81.0 125.0 16.0 120.0 178.0
4.1 43.0 75.0 9.5 81.0 125.0 16.3 125.0 184.0
4.2 43.0 75.0 9.6 87.0 133.0 16.5 125.0 184.0
4.3 47.0 80.0 9.7 87.0 133.0 16.8 125.0 184.0
4.4 47.0 80.0 9.8 87.0 133.0 17.0 125.0 184.0
4.5 47.0 80.0 9.9 87.0 133.0 17.3 130.0 191.0
4.6 47.0 80.0 10.0 87.0 133.0 17.5 130.0 191.0
4.7 47.0 80.0 10.1 87.0 133.0 17.8 130.0 191.0
4.8 52.0 86.0 10.2 87.0 133.0 18.0 130.0 191.0
4.9 52.0 86.0 10.3 87.0 133.0 18.5 135.0 198.0
5.0 52.0 86.0 10.4 87.0 133.0 18.8 135.0 198.0
5.1 52.0 86.0 10.5 87.0 133.0 19.0 135.0 198.0
5.2 52.0 86.0 10.6 87.0 133.0 19.3 140.0 205.0
5.3 52.0 86.0 10.7 94.0 142.0 19.5 140.0 205.0
5.4 57.0 93.0 10.8 94.0 142.0 19.8 140.0 205.0
5.5 57.0 93.0 10.9 94.0 142.0 20.0 140.0 205.0
Professional Quality HSS Co Drill Left Hand HSS Twist Drills HSS Jobber Drill Bit (SED-HTL) Professional Quality HSS Co Drill Left Hand HSS Twist Drills HSS Jobber Drill Bit (SED-HTL) Professional Quality HSS Co Drill Left Hand HSS Twist Drills HSS Jobber Drill Bit (SED-HTL)
