Twist Drill Bit
Jobber-length
High Speed Steel
Metal Drilling
Customized
DIN
Product Description
DIN340 Straight Shank drill bit HSS Long Twist Drill for Stainless Steel Metal Aluminium PVC Iron
Material: HSS and HSS Cobalt, HIGH SPEED STEEL
Process: Fully Ground
Length Standard: Taper Length DIN340 Long
Point Angle: 118 Degree General Point
Shank: Straight Shank
Flute Type: Type N Spiral Right Hand
Size: 1-13mm,1/64"- 1/2"
Surface Finish: Bright Finish
Application: For Stainless Steel Metal Aluminium PVC Iron
Type: Twist Drill Bit
Use: Metal Drilling.
| Product Name | DIN340 Straight Shank HSS Long Twist Drill Bit for Metal |
| Material | HSS (HSS Cobalt is Available) |
| Process | Fully Ground (Rolled & Polished, Rolled, Milled are Available) |
| Standard | Long DIN340 (DIN338, Stub DIN1897, Extra Long DIN1869, Blacksmith Reduced Shank 10mm, 13mm, DIN345 Taper Shank are Available) Long Taper Length (Jobber Length, Stub Screw Machine Length, Airctraft Extensoin, Extra Long 12", 18", 24", Silver & Deming 1/2" Reduced Shank are Available) |
| Size | 1-13mm,1/64"- 1/2" |
| Point Type | 118 Degree Regular Point (135 Degree Split Point, Turbo Max Point, Pilot Point are Available) |
| Shank Type | Straight Shank (Hex Shank, Tri-Flats Shank, Double R Hex Shank, Reduced Shank, Threaded Hex Shank, Taper Shank are Available) |
| Helix Angle | Regular Spiral Type N (Slow Spiral Type H, Fast Spiral Type W, Left Hand Spiral are Available) |
| Web & Flute Type | Regular Web & Flute (Thick Web with Parabolic Flute, Heavy Duty Web with Regular Flute are Available) |
| Surface Finish | Bright (Black Oxide, Amber Color, Titanium, Black & Gold, Black & Bright are Available) |
| Package | 10/5 Pcs in PVC Pouch, Plastic Box, Individually in Skin Card, Double Blister, Clamshell. |
| Features | 1.High-speed steel tools are good for most general purpose applications, offering a combination of hardness and toughness for wear resistance. 2.Universal 118° point shape for drilling a wide selection of materials. 3.Precision ground point, flutes, body, clearance and drill diameter for the ultimate in accuracy and performance. of the bit. |
