Best Quality HSS Jobber Drills Fully Ground HSS Drill Black&Amber Finish HSS Twist Drill Bit (SED-HSBA)

Quantity:
  • Customized

  • DIN

  • Jobber-length

  • Twist Drill Bit

  • High Speed Steel

  • Metal Drilling

  • SED-HSBA

  • 1mm-13mm

  • Black&Amber

  • Fully Ground

  • Metal Cutting

  • Punch,Box

  • 1000PCS Each Size

  • PVC Bag, Blister Card, Plastic Box

  • SGS

  • EASYDRILL

  • China

  • 820750900

  • 200, 000PCS/Month

  • Available | Customized Request

Product Description

Best quality HSS drills Fully Ground HSS drill Black&Amber Finish HSS Jobber Drill Bit

1. Material: 4241, 4341, 9341, 6542, M2, M35, and M42 +Co 5% etc. (pic:M2)
2. Manufacturing Art: Fully ground, roll forged and edge forged twist drill
3. Application: For drilling in steel, cast steel, malleable iron, sintered metal, non-ferrous metal and plastic,or wood.
4. Packing: Paper box, or Plastic box,punch bag,set case etc
5. Dia Size: 0.2mm-21mm
6.Surface finish:bright white,black,tin-coated, black&yellow,bronze coated etc (pic :black oxide)
7.Standard: DIN338,DIN345,DIN340,DIN1897 etc
8.118 degree or 135 split point.(pic: 135degree)

Metric Size are available ( DIN338 Standard ):
1.0mm ~ 13.0mm by 0.1mm
Set are available:
1.5 ~ 6.5mm x 13 PCS set
1.0 ~ 10mm x 19 PCS set
1.0 ~ 13mm x 25 PCS set

Inch Size are available ( ANSI B94.11M-1993 Standard ):
1/16" ~ 1/4" x 13 PCS set
1/16" ~ 3/8" x 21 PCS set
1/16" ~ 1/2" x 29 PCS set
Diameter (mm) Flute Length(mm) Overall Length (mm) Diameter (mm) Flute Length(mm) Overall Length(mm) Diameter (mm) Flute Length(mm) Overall Length(mm)
0.2 2.5 19.0 5.6 57.0 93.0 11.0 94.0 142.0
0.3 3.0 19.0 5.7 57.0 93.0 11.1 94.0 142.0
0.4 5.0 20.0 5.8 57.0 93.0 11.2 94.0 142.0
0.5 6.0 22.0 5.9 57.0 93.0 11.3 94.0 142.0
0.6 7.0 24.0 6.0 57.0 93.0 11.4 94.0 142.0
0.7 9.0 28.0 6.1 63.0 101.0 11.5 94.0 142.0
0.8 10.0 30.0 6.2 63.0 101.0 11.6 94.0 142.0
0.9 11.0 32.0 6.3 63.0 101.0 11.7 94.0 142.0
1.0 12.0 34.0 6.4 63.0 101.0 11.8 94.0 142.0
1.1 14.0 36.0 6.5 63.0 101.0 11.9 101.0 151.0
1.2 16.0 38.0 6.6 63.0 101.0 12.0 101.0 151.0
1.3 16.0 38.0 6.7 63.0 101.0 12.1 101.0 151.0
1.4 18.0 40.0 6.8 69.0 109.0 12.2 101.0 151.0
1.5 18.0 40.0 6.9 69.0 109.0 12.3 101.0 151.0
1.6 20.0 43.0 7.0 69.0 109.0 12.4 101.0 151.0
1.7 20.0 43.0 7.1 69.0 109.0 12.5 101.0 151.0
1.8 22.0 46.0 7.2 69.0 109.0 12.6 101.0 151.0
1.9 22.0 46.0 7.3 69.0 109.0 12.7 101.0 151.0
2.0 24.0 49.0 7.4 69.0 109.0 12.8 101.0 151.0
2.1 24.0 49.0 7.5 69.0 109.0 12.9 101.0 151.0
2.2 27.0 53.0 7.6 75.0 117.0 13.0 101.0 151.0
2.3 27.0 53.0 7.7 75.0 117.0 13.1 101.0 151.0
2.4 30.0 57.0 7.8 75.0 117.0 13.2 101.0 151.0
2.5 30.0 57.0 7.9 75.0 117.0 13.3 108.0 160.0
2.6 30.0 57.0 8.0 75.0 117.0 13.4 108.0 160.0
2.7 33.0 61.0 8.1 75.0 117.0 13.5 108.0 160.0
2.8 33.0 61.0 8.2 75.0 117.0 13.6 108.0 160.0
2.9 33.0 61.0 8.3 75.0 117.0 13.7 108.0 160.0
3.0 33.0 61.0 8.4 75.0 117.0 13.8 108.0 160.0
3.1 36.0 65.0 8.5 75.0 117.0 13.9 108.0 160.0
3.2 36.0 65.0 8.6 81.0 125.0 14.0 108.0 160.0
3.3 36.0 65.0 8.7 81.0 125.0 14.3 114.0 169.0
3.4 39.0 70.0 8.8 81.0 125.0 14.5 114.0 169.0
3.5 39.0 70.0 8.9 81.0 125.0 14.8 114.0 169.0
3.6 39.0 70.0 9.0 81.0 125.0 15.0 114.0 169.0
3.7 39.0 70.0 9.1 81.0 125.0 15.3 120.0 178.0
3.8 43.0 75.0 9.2 81.0 125.0 15.5 120.0 178.0
3.9 43.0 75.0 9.3 81.0 125.0 15.8 120.0 178.0
4.0 43.0 75.0 9.4 81.0 125.0 16.0 120.0 178.0
4.1 43.0 75.0 9.5 81.0 125.0 16.3 125.0 184.0
4.2 43.0 75.0 9.6 87.0 133.0 16.5 125.0 184.0
4.3 47.0 80.0 9.7 87.0 133.0 16.8 125.0 184.0
4.4 47.0 80.0 9.8 87.0 133.0 17.0 125.0 184.0
4.5 47.0 80.0 9.9 87.0 133.0 17.3 130.0 191.0
4.6 47.0 80.0 10.0 87.0 133.0 17.5 130.0 191.0
4.7 47.0 80.0 10.1 87.0 133.0 17.8 130.0 191.0
4.8 52.0 86.0 10.2 87.0 133.0 18.0 130.0 191.0
4.9 52.0 86.0 10.3 87.0 133.0 18.5 135.0 198.0
5.0 52.0 86.0 10.4 87.0 133.0 18.8 135.0 198.0
5.1 52.0 86.0 10.5 87.0 133.0 19.0 135.0 198.0
5.2 52.0 86.0 10.6 87.0 133.0 19.3 140.0 205.0
5.3 52.0 86.0 10.7 94.0 142.0 19.5 140.0 205.0
5.4 57.0 93.0 10.8 94.0 142.0 19.8 140.0 205.0
5.5 57.0 93.0 10.9 94.0 142.0 20.0 140.0 205.0
Best Quality HSS Jobber Drills Fully Ground HSS Drill Black&Amber Finish HSS Twist Drill Bit (SED-HSBA)
Best Quality HSS Jobber Drills Fully Ground HSS Drill Black&Amber Finish HSS Twist Drill Bit (SED-HSBA) Best Quality HSS Jobber Drills Fully Ground HSS Drill Black&Amber Finish HSS Twist Drill Bit (SED-HSBA) Best Quality HSS Jobber Drills Fully Ground HSS Drill Black&Amber Finish HSS Twist Drill Bit (SED-HSBA)
