| Quantity: | |
|---|---|
Non-Standard
Uncoated
H8
Spiral
Taper Shank
Machine Reamer
SED-MR-TS
High Speed Steel
Conic Reamer
Straight Shank
Spiral Flute
20PCS
Original
Plastic Tube
1mm-12mm
EASYDRILL
China
820770900
50000PCS/Month
US$ 20/Piece 1 Piece(Min.Order) | Request Sample
Product Description
HSS Morse Taper Shank Machine Reamer with spiral flute
Material: HSS
Size | Flute | Overall | Shank |
(mm) | Length | Length | Taper |
| (mm) | (mm) |
|
5 | 23 | 133 | MT1 |
6 | 26 | 138 | MT1 |
7 | 31 | 150 | MT1 |
8 | 33 | 156 | MT1 |
9 | 36 | 162 | MT1 |
10 | 38 | 168 | MT1 |
11 | 41 | 175 | MT1 |
12 | 44 | 185 | MT1 |
13 | 44 | 182 | MT1 |
14 | 47 | 189 | MT1 |
15 | 50 | 204 | MT2 |
16 | 52 | 210 | MT2 |
17 | 54 | 214 | MT2 |
18 | 56 | 219 | MT2 |
19 | 58 | 223 | MT2 |
20 | 60 | 228 | MT2 |
21 | 62 | 232 | MT2 |
22 | 64 | 237 | MT2 |
23 | 66 | 241 | MT2 |
24 | 68 | 268 | MT3 |
25 | 68 | 268 | MT3 |
26 | 70 | 273 | MT3 |
27 | 71 | 277 | MT3 |
28 | 71 | 277 | MT3 |
29 | 73 | 281 | MT3 |
30 | 73 | 281 | MT3 |
31 | 75 | 285 | MT3 |
32 | 77 | 317 | MT4 |
33 | 77 | 317 | MT4 |
34 | 78 | 321 | MT4 |
35 | 78 | 321 | MT4 |
36 | 79 | 325 | MT4 |
37 | 79 | 325 | MT4 |
38 | 81 | 329 | MT4 |
40 | 81 | 329 | MT4 |
