DIN208 Morse Taper Shank Machine Chucking Reamer (SED-MTR)

Quantity:
Inquire Add to Basket

  • Uncoated

  • Straight Tooth

  • Sparse Tooth

  • Indexable Type

  • High Speed Steel

  • Vertical Milling Cutter

  • SED-MTR

  • Straight Shank

  • Straight Flute

  • 20PCS

  • Original

  • Plastic Tube

  • 1mm-12mm

  • EASYDRILL

  • China

  • 820770900

  • 50000PCS/Month

  • US$ 50/Piece 1 Piece(Min.Order) | Request Sample

Product Description

Din208 Morse Taper Shank Machine Chucking Reamer

High speed steel,tolerance H7.
Type: Chucking Reamer, Drilling Tool
Machine Type: Boring Machine
Supply Ability : 2000 Piece/Pieces per Month
Size Flute Overall Shank
(mm) Length Length Taper
(mm) (mm)
5 23 133 MT1
6 26 138 MT1
7 31 150 MT1
8 33 156 MT1
9 36 162 MT1
10 38 168 MT1
11 41 175 MT1
12 44 185 MT1
13 44 182 MT1
14 47 189 MT1
15 50 204 MT2
16 52 210 MT2
17 54 214 MT2
18 56 219 MT2
19 58 223 MT2
20 60 228 MT2
21 62 232 MT2
22 64 237 MT2
23 66 241 MT2
24 68 268 MT3
25 68 268 MT3
26 70 273 MT3
27 71 277 MT3
28 71 277 MT3
29 73 281 MT3
30 73 281 MT3
31 75 285 MT3
32 77 317 MT4
33 77 317 MT4
34 78 321 MT4
35 78 321 MT4
36 79 325 MT4
37 79 325 MT4
38 81 329 MT4
40 81 329 MT4
DIN208 Morse Taper Shank Machine Chucking Reamer (SED-MTR)
DIN208 Morse Taper Shank Machine Chucking Reamer (SED-MTR) DIN208 Morse Taper Shank Machine Chucking Reamer (SED-MTR) DIN208 Morse Taper Shank Machine Chucking Reamer (SED-MTR)
