HSS Countersink with Single Flute ISO3294 (SED-CSSF)

Quantity:
  • Customized

  • DIN, AISI

  • Jobber-length

  • Countersink Drill Bit

  • High Speed Steel

  • Metal Drilling

  • SED-CSSF

  • Box

  • 200PCS

  • Single Flute

  • Round Shank or Quick Change Shank

  • Original Color

  • Box

  • single flutes

  • EASYDRILL

  • China

  • 80000PCS/Month

  • Available | Customized Request

Product Description

HSS Countersink with Single Flute ISO3294

1. Ideal for chatter-free and burr-free work on sheet metal, nonferrous metal, cast iron, light metals;

2. It's designed for fast shearing and chatterless cuts;
3. It's with an exceptionally fine finish and can be run at maximum speed;
4. The cutting edges quickly center in hole and produce a smaller chip load for chatterless machining;
5. There are single flute, 3 flute, 5 flute, 6 flute available for your choice.
6.Standard:DIN335C

7.HSS, with cylindrical shank
8.CBN-deep-ground;Countersinks are deep-ground in the CBN Flutes. The 90° cone corresponds with the shape of the counter-sink screw or bolt head. Also available in 60°, 75°, and 120° versions. Radial back-off clearance makes it possible to work without rattling, and also removes chipos and swarf perfectly.
Size Shank Overall Length
3/16" 3/16" 1-1/2"
1/4" 1/4" 1-1/2"
5/16" 1/4" 1-5/8"
3/8" 1/4" 1-3/4"
1/2" 1/4" 2"
5/8" 3/8" 2-1/4"
3/4" 1/2" 2-5/8"
7/8" 1/2" 2-3/4"
1" 1/2" 2-3/4"
1-1/4" 3/4" 3"
1-1/2" 3/4" 3-1/4"
2" 3/4" 3-1/2"
HSS Countersink with Single Flute ISO3294 (SED-CSSF)HSS Countersink with Single Flute ISO3294 (SED-CSSF)HSS Countersink with Single Flute ISO3294 (SED-CSSF)HSS Countersink with Single Flute ISO3294 (SED-CSSF)HSS Countersink with Single Flute ISO3294 (SED-CSSF)
