Yg10X 330mm Tungsten Carbide Rods Cemented Carbide Rods (SED-CR)

Quantity:
  • Customized

  • Center Drill Bit

  • Tungsten Carbide

  • Metal Drilling

  • Plastic Tube

  • 1mm-20mm

  • SED-CR

  • EASYDRILL

  • China

  • 820770900

  • 50000PCS/Month

  • US$ 20/Piece 1 Piece(Min.Order) | Request Sample

Product Description

YG10X 330mm tungsten carbide rods cemented carbide rods

1. WC grain size Range: 0.3-2um
2. Diameter Range: 2-30mm
3. Length Range: 10-335mm
4. Virgin or not: 100% Virgin
Application: Steel, Cast Iron, Hard Metal
Samples: Available
OEM: Accept
Export Markets: Global
Performance of Different Grade
GRADE

Co Content

%

Grain Size

μm

Density

g/cm3

Hardness

HRA

T.R.S

N/mm2

Usage

YG10X

10 0.8 14.6 91.5 3800 Use widely, with good hot hardness. Suitable for milling and drilling general steel
under 45 HRC and Aluminum, etc at a low cutting speed. Recommend use this
grade to make the twist drills, end mills, etc.
MTS30UF 10 0.6 14.5 92 4500 Suitable for milling and drilling general steel under HRC 55, cast iron, stainless
steel, aluminum alloy, etc. Recommend to make the drills, milling cutters, reamers
and taps.
MTS25UF 12 0.4 14.3 92.5 4300 Suitble for milling titanium alloy, hardened steel, refractory alloy under HRC 63.
Recommend to make end mills with high cutting speed and reamer.
Yg10X 330mm Tungsten Carbide Rods Cemented Carbide Rods (SED-CR)
Yg10X 330mm Tungsten Carbide Rods Cemented Carbide Rods (SED-CR) Yg10X 330mm Tungsten Carbide Rods Cemented Carbide Rods (SED-CR) Yg10X 330mm Tungsten Carbide Rods Cemented Carbide Rods (SED-CR)
Yg10X 330mm Tungsten Carbide Rods Cemented Carbide Rods (SED-CR)
Yg10X 330mm Tungsten Carbide Rods Cemented Carbide Rods (SED-CR)
