Professional Diamond Segments for Cutting Masonry, Concrete, Asphalt etc (SED-DS)

Quantity:



Inquire Add to Basket

Type:
Natural Diamond
Surface Finishing:
CrN
Blade Material:
Diamond
Size:
Customized
Manufacturing Art:
Welded or Sintered
Quality:
High,Medium,Economic
Model NO.:
SED-DS
Min Quantity:
200PCS/Size
Transport Package:
PVC, Box or as Per Request
Specification:
MPA, CE, ISO9001, SGS
Trademark:
EASYDRILL
Origin:
China
HS Code:
820790100
Production Capacity:
50, 000PCS/Month
Samples:
US$ 10/Piece 1 Piece(Min.Order) | Request Sample

Product Description

Product Description

Diamond Segments for diamond tools

Material:Diamond, alloy powder;imported cobalt powder and nickel powder, and high-quality diamond single crystals.
Manufacturing Arts:Sinter;

Quality Available:High, Medium, Economic
Welding Method:High-Frequency,Silver Brazed, Oxygen Fired Brazed;
Usage: wet Stone Cutting,easy and smooth cutting with Long life and stable performance
Application:Granite; Marble; Sandstone; Limestone.
Machine: Bridge saw, stone saw, multi-saw
Steel Core Thickness(Mm):2.2mm-10.0mm
Through the validation tested scientific formula.
Strict product quality inspection processes.
Support: OEM.

Diameter (mm)	Specification LxWxH (mm)	Segment Number	Cutting depth (m2/day)	Feed speed (m/min)	Cutting speed(m2/h)	Output(m2/disc)
200	40x3.2x8/10	14	20	3~5	1~3	12~15
250	40x3.2x8/10	18	20	3~5	1~3	14~17
300	40x3.2x10/12	21	20	3~5	1~3	16~20
350	40x3.2x10/12	24	20	3~5	1~3	18~23
400	40x3.4x10/12	28	20	3~5	1~3	20~25
450	40x3.6x10/12	32	20~50	2~4	1~3	22~27
500	40x4x10/12	36	20~50	2~4	1~3	35~47
550	40x4.6x12	40	20~50	2~4	1~3	40~52
600	40x4.6x10/12	42	20~50	2~4	1~3	43~57
700	40x5x10/12	46	20~50	2~4	1~3	65~85
750	40x5.5x10/12	48	20~50	2~4	1~3	77~97
800	40x5.5x10/12	50	20~50	2~4	1~3	85~105
850	40x6.0x10/12	54	20~50	2~4	1~3	92~110
900	24x6.9/6.1x13	64	30~60	1.5~4	2~3	200~270
1000	24x6.9/6.1x13	70	30~60	1.5~4	2~3	220~300
1100	24x7.4/6.6x13	74	30~60	1.5~4	1.5~3	1.5~3
1200	24x7.4/6.6x13	80	30~60	1.5~4	1.5~3	1.5~3
1300	24x8.4/7.6x13	88	30~60	1.5~4	1.5~3	1.5~3
1400	24x8.4/7.6x13	96	30~60	1.5~4	1.5~3	1.5~3
1500	24x9.2/8.4x13	100	30~60	1.5~4	1.5~3	1.5~3
1600	24x9.4/8.4x13	108	30~60	1.5~4	1.5~3	1.5~3
1700	24x9.2/8.4x13	112	30~60	1.5~4	1.5~3	1.5~3
1800	24x9.9/9.1x13	120	30~60	1.5~4	1.5~3	1.5~3
2000	24x11/10x15	128	30~60	2.5~5	2~3	560~650
2200	24x11/10x15	132	30~60	2.5~5	2~3	580~670
2500	24x12.5/11.5x20	140	30~60	2.5~5	2~3	850~950
2700	24x12.5/11.5x20	140	30~60	2.5~5	2~3	900~1000
3000	24x12.5/11.5x20	160	30~60	2.5~5	2~3	1100~1200
3500	24x12.5/11.5x20	180	30~60	2.5~5	2~3	1250~1350
