20PCS SDS Drills SDS Chisels SDS Plus Shank Electric Hammer Drill Bits Sets (SED-SDC20)

Quantity:
Inquire Add to Basket

  • Customized

  • DIN

  • Core Drill Bit

  • High Carbon Steel

  • Masonry Drilling, Concrete Drilling

  • 200sets

  • SED-SDC20

  • Plastic Box

  • Straight Tip

  • Single

  • SDS Plus

  • Alumium Plastic Box

  • SGS, ISO9001

  • EASYDRILL

  • China

  • 820750900

  • 30, 000sets/Month

  • US$ 10/Piece 1 Piece(Min.Order) | Request Sample

Product Description

20PCS SDS drill bits SDS chisels SDS Plus Shank Electric Hammer Drill Bits Sets

1.Material : 40CR
2.tip: straight "-" tip. YG8C
3.Sizes:5,6X110MM*2pcs; 8*110mm*2pcs,10*110mm,
6,8,10*160mm*2pcs, ,12*160mm,8,10*210mm,8,10,12,14*260mm.
4.Package: Aluminium box.size: 46.5x18x6cm.
5.flute: single flute.
6.for drilling concrete,granite,brick etc
7. extremely robustfast drill bits for SDS MAX systems with brazed carbide tip &shot blast finish.
Item Name Size(mm) pcs
SDS plus drill bits 5*110 2
6*110 2
6*160 2
8*160 2
10*160 2
8*110 2
10*110 1
12*160 1
8*210 1
10*210 1
8,10,12,14*260 4

main specifications:
Diameter x Overall Length(mm) Working Length(mm) Diameter x Overall Length(mm) Working Length(mm)
4.0 x 110 45 14.0 x 160 80
4.0 x 160 95 14.0 x 200 120
5.0 x 110 45 14.0 x 260 180
5.0 x 160 95 14.0 x 300 220
5.0 x 210 147 14.0 x 460 380
5.0 x 260 147 14.0 x 600 520
5.0 x 310 247 14.0 x 1000 920
6.0 x 110 45 15.0 x 160 80
6.0 x 160 97 15.0 x 200 120
6.0 x 210 147 15.0 x 260 180
6.0 x 260 197 15.0 x 460 380
6.0 x 460 397 16.0 x 160 80
7.0 x 110 45 16.0 x 200 120
7.0 x 160 97 16.0 x 250 180
7.0 x 210 147 16.0 x 300 230
7.0 x 260 147 16.0 x 460 380
8.0 x 110 45 16.0 x 600 520
8.0 x 160 97 16.0 x 800 720
8.0 x 210 147 16.0 x 1000 920
8.0 x 260 197 17.0 x 200 120
8.0 x 310 247 18.0 x 200 120
8.0 x 460 397 18.0 x 250 175
8.0 x 610 545 18.0 x 300 220
9.0 x 160 97 18.0 x 460 380
9.0 x 210 147 18.0 x 600 520
10.0 x 110 45 18.0 x 1000 920
10.0 x 160 97 19.0 x 200 120
10.0 x 210 147 19.0 x 460 380
10.0 x 260 197 20.0 x 200 120
10.0 x 310 247 20.0 x 300 220
10.0 x 360 297 20.0 x 460 380
10.0 x 460 397 20.0 x 600 520
10.0 x 600 537 20.0 x 1000 920
10.0 x 1000 937 22.0 x 250 175
11.0 x 160 95 22.0 x 450 370
11.0 x 210 145 22.0 x 600 520
11.0 x 260 195 22.0 x 1000 920
11.0 x 300 235 24.0 x 250 175
12.0 x 160 85 24.0 x 450 370
12.0 x 210 135 25.0 x 250 175
12.0 x 260 185 25.0 x 450 370
12.0 x 310 235 25.0 x 600 520
12.0 x 460 385 25.0 x 1000 920
12.0 x 600 525 26.0 x 250 175
12.0 x 1000 920 26.0 x 450 370
13.0 x 160 80 28.0 x 450 370
13.0 x 210 130 30.0 x 460 380
13.0 x 260 180
13.0 x 300 220
13.0 x 460 380
20PCS SDS Drills SDS Chisels SDS Plus Shank Electric Hammer Drill Bits Sets (SED-SDC20) 20PCS SDS Drills SDS Chisels SDS Plus Shank Electric Hammer Drill Bits Sets (SED-SDC20) 20PCS SDS Drills SDS Chisels SDS Plus Shank Electric Hammer Drill Bits Sets (SED-SDC20)
20PCS SDS Drills SDS Chisels SDS Plus Shank Electric Hammer Drill Bits Sets (SED-SDC20)
20PCS SDS Drills SDS Chisels SDS Plus Shank Electric Hammer Drill Bits Sets (SED-SDC20)

20PCS SDS Drills SDS Chisels SDS Plus Shank Electric Hammer Drill Bits Sets (SED-SDC20) 20PCS SDS Drills SDS Chisels SDS Plus Shank Electric Hammer Drill Bits Sets (SED-SDC20) 20PCS SDS Drills SDS Chisels SDS Plus Shank Electric Hammer Drill Bits Sets (SED-SDC20)
20PCS SDS Drills SDS Chisels SDS Plus Shank Electric Hammer Drill Bits Sets (SED-SDC20)
